Capapcity | 0~1t | Zero balance | ±1%R.O | ||
Rated output | 1.5 ± 10% mV/V | Temp.effect on zero | 0.1R.O./10℃ | ||
Non-linearity | 0.3~0.5 % R.O. | Temp.effect on output | 0.1 R.O./10℃ | ||
Hysteresis | 0.3~0.5 % R.O. | Input impedance | 350 ± 50Ω | ||
Repeatability | 0.2% R.O. | Out impedance | 350 ± 5Ω | ||
Temperature | - 20 ~ 80ºC | Insulation | ≥5000MΩ/100VDC | ||
Compensated temp range | -10℃~60℃ | Safe overload | 120% R.C. | ||
Recommended excitation | 5~10V DC | Ultimate overload | 150% R.C. | ||
Maximum Excitation | 15V DC | Protection class | IP64 (or IP67) | ||
Cable | 4-core shielded cable Ø4* 3m |
